EU Electricity Network Codes

EU Electricity Network Codes. What are they? Who do they apply to? What are similarities and differences between a network code and a guideline?

This article provides more information about the EU Electricity network Codes.



What is a network code?

A network code (NC) is a set of technical rules enabling the development of the internal energy market in Europe. The NCs address the major barriers impeding the cross-border flow of electricity and gas, transforming a mere patchwork of national energy markets into a single European energy market. The NCs guide the integrated operation of cross-border energy networks to allow for increasing competitiveness, more cost-efficient integration of renewables and a secure supply of energy at prices that are affordable for the European consumers.

Network codes address market, system operation and grid connection rules, the so-called ‘’software’’ of the EU internal energy market. The Trans-European Energy Networks (TEN-E) Regulation addresses cross- border infrastructure investment, the ‘’hardware’’ of the internal energy market.



Background to the electricity network codes and guidelines

The currently adopted EU electricity network codes originate in the 2009 Third Energy Package. The Third Energy Package is a set of legislations that are part of the process of the liberalisation of the electricity and gas markets initiated back in the mid-1990s. More specifically, Regulation (EC) No 714/2009 sets out the areas in which electricity network codes can be developed and a process for developing them.

In 2017, after a 4-year-long co-creation process by the European Network of Transmission System Operators for Electricity (ENTSO-E)the European Union Agency for the Cooperation of Energy Regulators (ACER), the European Commission (EC) and many involved stakeholders from across the electricity sector, eight network codes and guidelines have been developed and entered into force. After the development of the network codes, the implementation phase started.



Eight adopted electricity network codes and guidelines

Currently, there are eight network codes and guidelines that have been published in the Official Journal of the European Union as Commission Regulations. Commission Regulations usually enter into force twenty days after publication, unless explicitly stated otherwiseThe figure below illustrates how these eight regulations can be subdivided into three groups.

Below these eight regulations are listed and some examples of topics covered by each of them is given. More details can be found in the report The EU electricity network codes (2019 ed.). These topics are also covered in the online course the Evolution of electricity markets in Europe.

  • The capacity allocation and congestion management guideline (CACM GL) – published on 25 July 2015. ThCACM GL fosters an efficient integration of the European power markets at the day-ahead and intraday timeframe. The guideline covers topics such as the governance of power exchanges, the criteria for the bidding zone delineation and the allocation of cross-zonal transmission capacity at day-ahead and intraday timeframe.
  • The forward capacity allocation guidelines (FCA GL) – published on 27 September 2016The FCA GL harmonises the allocation rules for long-term cross-zonal transmission rights. Thguideline covers topics such as setting up a pan-European platform for the allocation of long-term transmission rights, the types of long-term transmission rights and rules around curtailment of long-term transmission rights.
  • The electricity balancing guideline (EB GL) – published on 23 November 2017The EB GL aims at harmonising and integrating the European balancing energy markets. The guideline covers topics such as the European platforms for the exchange of balancing energy, the imbalance settlement and the allocation of cross-zonal transmission capacity for the balancing timeframe.
  • The network code on requirements for grid connection of generators (RfG NC)  published on 14 April 2016The RfG NC covers the requirements for generators (synchronously and as-synchronously connected) to be connected. The RfG NC fosters the robustness of the European electricity network and intends to establish a level-playing field in terms of connection requirements for generators.  Examples of topics covered are frequency bands to remain connected, voltage limits and reconnection and re-synchronisation capabilities.
  • The demand connection network code (DC NC) – published on 18 August 2016The DC NC covers the requirements for demand facilities or distribution systems to be connected. The DC NC fosters the robustness of the European electricity network and intends to establish a level-playing field in terms of connection requirements for load. Similarly as under the RfG NC, examples are frequency bands to remain connected, voltage limits and reconnection and re-synchronisation capabilities.
  • The requirements for grid connection of high voltage direct current systems and direct current-connected power park modules network code (HVDC NC) – published on 8 September 2016. The HVDC NC covers the requirements for long distance direct current (DC) connections. The HVDC NC fosters the robustness of the European electricity network and intends to establish a level-playing field in terms of connection requirements for HVDC connections.
  • The electricity transmission system operation guideline (SO GL published on 25 August 2017The SO GL sets minimum system security, operational planning and frequency management standards to ensure safe and coordinated system operation across EuropeExamples of topics that are covered are balancing capacity requirements and the setting up of regional security centres.

How were these network codes developed?

The key actors involved in the development of the network codes were: the European Commission, the Agency for the Cooperation of Energy Regulators (ACER) and the European Network of Transmission System Operators for Electricity (ENTSO-E). However, it does not mean that their role is equal.

The development process for the network codes coming out of the Third Energy Package is detailed in Regulation (EC) No 714/2009. First, the European Commission, after having consulted ACER, ENTSO-E and other relevant stakeholders, drafted annual priority lists, which identified possible areas for network codes development.

Following the Commission’s request, ACER prepared non-binding Framework Guidelines, stipulating the key principles for the development of the network codes. The European Commission requested ENTSO-E to draft the text of the network codes, which should stay in line with the relevant Framework Guideline developed by ACER. The drafts became a network codes after their adoption was recommended to the European Commission by ACER and approved by a committee composed of national experts (‘Electricity Cross-Border Committee’) through the Comitology procedure. At the end of the Comitology procedure, the Commission adopted the network codes as implementing acts.

For more details about this development procedure please consult The EU electricity network codes and guidelines: a legal perspective.



Who do they apply to?

The network codes concern the operation of the energy (electricity and gas) networks connecting two or more EU Member States and countries, which constitute a part of the European Economic Area. However, over the past few years some non-EU countries opted for a voluntary adoption of NCs, e.g. the Energy Community Contracting Parties.



Similarities and differences between a network code and a guideline

Commonly, we refer to these eight regulations as ‘network codes,’ however, not all of them are legally defined as such. Just four out of eight are defined as network codes (ER NC, RfG NC, DC NC and HVDC NC), the other four are, instead, referred to as guidelines (CACM GL, FCA GL, EB GL and SO GL). Initially, all eight were planned to be developed as network codes, yet some became guidelines in the development process. In theory, network codes and guidelines can cover the same topics. In practice, however, it is observed that some topics lend themselves better to guidelines than to network codes and others vice versa.

Network codes and guidelines are similar in that they carry the same legal weight (both are Commission regulations and are legally binding), are directly applicable (they do not need to be transposed into national law) and are subject to the same formal adoption procedure (‘old’ Comitology procedure). Network codes and guidelines differ from each other regarding their legal basis, the stakeholder involvement, their amendment process, topics and scope, and the adoption of further rules during the implementation phase.

The main practical difference is the work to be done during the implementation phaseIn general, network codes are more detailed than guidelines. This is because guidelines shift a larger share of the further development to the implementation phase, which can allow for more flexibility but can also slow down or complicate the overall process. Guidelines include processes in which TSOs or Nominated Electricity Market Operators (NEMOs) must develop so-called ‘Terms and Conditions or Methodologies (TCM).’ TCMs are comprehensive (legal) texts that are often referred to as ‘methodologies.’ In most cases, methodologies have to be jointly developed by all TSOs or all NEMOs at the pan-European level or by the relevant TSOs/NEMOs at the regional or national levels. Depending on the scope of the methodologies, the Third Package foresaw their approval either by all National Regulatory Authorities NRAs (pan-European methodologies) or the relevant subset of NRAs (regional and national methodologies). In certain cases, a decision is to be referred to ACER. The implementation of the TCMs foreseen in the first generation of network codes and guidelines will continue until around 2025.

More details about the difference between a network code and a guideline can also be found here.



Clean Energy Package: additional network codes and guideline areas

In its Clean Energy Package (CEP), issued in November 2016 and approved in late 2018, the European Commission proposed a recast of Regulation (EC) 714/2009. The adoption of the Clean Energy Package brought significant changes for both existing and future generations of EU network codes and guidelines.

First, the recast of Regulation (EC) 714/2009 includes provisions that modify the operation of a number of the network codes and guidelines. Also, additional areas for a ‘’second generation of network codes and guidelines’’ were identified. Examples are rules on demand response, including aggregation, energy storage, and demand curtailment and rules for the non-discriminatory, transparent provision of non-frequency ancillary services. For a more detailed discussion about this second generation of network codes, please consult the report ‘INTERRFACE project: review of D2.4 regulatory framework’ and our relevant topic of the month posts.

Second, the development process saw a shift in roles and responsibilities. The strong role of ENTSO-E in drafting the network codes was reducedThe CEP also mandates the establishment of an EU DSO entity to involve Distribution System Operators (DSOs) in the network code and guideline drafting process. The role of ACER in the development phase is expected to increase. Another change concerns the time interval in which the European Commission is required to compile a priority list for new network codes.

Third, changes were introduced to the adoption process for both TCMs and new network codes and guidelines. Regarding TCMs, ACER now directly decides on the methodologies with a pan-European scale (former ‘all NRA’ decisions). Regarding network codes and guidelines, the Clean Energy Package distinguishes between the adoption of network codes and guidelines as implementing or delegated acts. Depending on the type of act, the European institutions and stakeholders have different rights and possibilities to intervene in the adoption process.



If you still have questions or doubt about the topic, do not hesitate to contact one of our academic experts:

Tim Schittekatte,  Valerie Reif
